Fixed & Swing Jaw Plates
Toothed manganese jaw plates for selected crusher models. The photograph shows plate geometry; fixed or swing position must be confirmed by part number.
- IdentificationPart number / drawing
- SupplyConfirmed on enquiry
Jaw crushers
The primary crusher is where throughput is won or lost
Jaw plate profile and condition affect feed grip, capacity and product size. Uneven wear, unsuitable settings or an incorrect profile can reduce performance.
We supply jaw plates in the profile and grade that matches your feed, along with the cheek plates, toggle group and structural castings that surround them, so a shutdown kit arrives complete.
- Fixed and swing jaws in three tooth profiles
- Mn18Cr2 and Mn22Cr2 manganese, plus hardened plate grades
- Cheek plates, toggle plates, seats, tension rods and springs
- Jaw stock and pitman castings, bare or fully machined
Selected Metso C-SeriesSandvik CJ / QJ
Component range
Parts we supply for jaw crushers
Jaw plate and structural component examples, with additional mechanical spares reviewed by part number.
Reinforced Jaw Plate Options
Jaw plates with a visible reinforcement pattern. Insert material, alloy and suitability require the supplier specification; appearance alone does not establish TiC content.
- IdentificationPart number / drawing
- SupplyConfirmed on enquiry
Frame & Side Plate Components
Machined structural side plates. These are distinct from the replaceable cheek liners inside the crushing chamber.
- IdentificationPart number / drawing
- SupplyConfirmed on enquiry
Cheek Plates
Replaceable chamber side liners, selected by crusher model, position and part number. Request the drawing and item-specific photograph with the quotation.
- IdentificationPart number / drawing
- SupplyConfirmed on enquiry
Toggle Plates & Seats
Load-transmitting toggle components and seats. Overload protection is model-specific; use the specified geometry and material. Request an item-specific photograph.
- IdentificationPart number / drawing
- SupplyConfirmed on enquiry
Pitman, Shaft & Tension Components
Pitman, eccentric shaft, flywheel, tension rod and spring enquiries are reviewed by exact machine reference. Assembly scope and photographs are confirmed for the quoted item.
- IdentificationPart number / drawing
- SupplyConfirmed on enquiry
Compatibility
Jaw crusher families we cover
From the compact C80 and CJ211 through to the C200 and CJ815. If your model is not listed, send it anyway.
Model names are identification references only. Exact part number, machine serial number and configuration must be checked before supply.
| Machine family | Models | Parts typically supplied |
|---|---|---|
| Metso C-Series | C80, C96, C100, C106, C110 | Fixed jaw, swing jaw, cheek plate, toggle plate, seat |
| Metso C-Series | C120, C130, C140, C145 | Fixed jaw, swing jaw, cheek plate, toggle plate, jaw stock |
| Metso C-Series heavy | C150, C160, C200 | Jaw plates, cheek plates, toggle group, pitman casting |
| Metso Lokotrack | LT96, LT106, LT110, LT120, LT130 | Jaw plates, cheek plates, toggle plate, seats |
| Sandvik CJ | CJ211, CJ409, CJ411, CJ412 | Fixed jaw, swing jaw, cheek plate, toggle plate, tension rod |
| Sandvik CJ heavy | CJ612, CJ613, CJ615, CJ815 | Jaw plates, cheek plates, toggle group, jaw stock |
| Sandvik QJ mobile | QJ241, QJ341, QJ351 | Jaw plates, cheek plates, toggle plate, toggle seat |
Profile selection
Match the tooth profile to the feed
Jaw plate profile, feed grading, material properties, settings and operating practice all affect wear life. Review them together when selecting a replacement.
| Selection item | Review required |
|---|---|
| Tooth profile | Use an approved profile matched to feed grading, abrasiveness and product requirements |
| Material grade | Review the complete alloy specification and operating history |
| Fixed or swing position | Confirm individual part numbers and installation instructions |
| Plate rotation or interchange | Only where permitted by the design; follow equipment instructions and wear limits |
Product photographs
Jaw component examples
Click any image to view it larger.
Questions
Jaw crusher parts, answered
What customers ask before they order jaw plates and spares.
Choose a jaw profile approved for the crusher and suitable for feed size, abrasiveness, fines and required product. A smooth or coarse-tooth profile does not universally improve throughput. Send the current part number and duty for review.
We accept enquiries for selected Metso C-Series and Sandvik CJ jaw crushers, including relevant mobile machines. The installed crusher model and serial number are needed to identify a part; a mobile plant designation alone may be insufficient.
Match the profile and grade to the duty, maintain suitable feeding and settings, and follow the equipment instructions for wear limits. Rotate or interchange plates only where that particular design permits it. Higher manganese content does not guarantee longer service life.
Yes. Fixed jaw, swing jaw, cheek plates, toggle plate and the correct bolts can be quoted as one shutdown kit. Give us the machine model and we will list what a full set normally comprises so nothing is left behind in stores.
Tell us the machine and the feed
Send the jaw crusher model, the rock type and the feed size. We will recommend a profile and a grade, then quote the full set.
